Q1: Why does drive system need a DC reactor?
In drive systems, especially motor systems driven by frequency converters or inverters, the rectifier generates current ripple and surge impacts when converting AC to DC. Without a DC reactor, these current fluctuations directly affect the DC bus and power devices, causing capacitors, inductors, and IGBTs to experience significant stress, leading to overheating or shortened lifespan. Installing a DC link reactor smooths the DC current, suppresses harmonics and surge currents, thereby protecting equipment, improving system stability, and enhancing overall power quality.
Q2: Where are DC reactors used?
DC chokes for vfd are primarily used in DC circuits where current fluctuations need to be controlled, including:
DC bus circuits of inverters or frequency converters for motor drive systems; High-power rectifier power supplies or power electronic equipment to suppress rectified current ripple; In photovoltaic inverters, battery energy storage systems, or UPS power supplies to improve DC bus stability and power quality; In various industrial drive equipment to reduce the impact of surge currents on sensitive components and improve system reliability.
In short, DC link chokes can be considered for use in any power electronic system where there are risks of current fluctuations, harmonics, or surges in the DC circuit.
