    5V 20A 100W SMPS Switching Power Supply

    0 review(s) | Add your review
    SKU: PH-SMPS-100-5
    $58.15
    ● Features a steady 5V/20A/100W output to provide dependable power for your equipment. ● Free air convection cooling provides reliable heat dissipation without noise. ● Rigorous 100% full load burn-in test guarantees reliable long-term operation. ● Low cost and high reliability make it an economical and trustworthy solution.
    🚚 Free shipping
    ⏱️ Delivery: 6-12 days
    🔙 30-day Returns
    Related products

    12V 8A 100W SMPS Switching Power Supply

    ● Designed to produce a steady 12V, 8.5A, 100W output for long-lasting power supply. ● Built-in short-circuit and overload protection to safeguard your devices and ensure stable operation. ● Utilizes free air convection for quiet, enhancing reliability and extending service life.
    $58.15

    24V 4A 100W SMPS Switching Power Supply

    ● Generates a steady 24V output with 4.5A current and 100W power to support long‑term stable operation. ● Small size saves space while delivering full rated power. ● Reliable cooling via free air convection for stable and quiet operation. ● Compact design with clearly labeled terminals for quick and simple wiring.
    $58.15

    48V 2A 100W SMPS Switching Power Supply

    ● Offers a reliable 100W power output, designed to support your equipment with stable performance. ● Free air convection cooling ensures stable operation without the need for a fan. ● Power-on LED indicator for clear and immediate operational status feedback. ● Low cost combined with high reliability delivers exceptional value.
    $58.15

    12V 4A 50W SMPS Switching Power Supply

    ● Provides steady 50W 12V power to ensure consistent, dependable device operation. ● Passive free-air convection keeps the unit cool without noisy fans. ● 100% full-load burn-in tested for enhanced long-term reliability. ● Ideal for LED strips, computers, printers, security camera systems, and factory automation controllers.
    $54.15

    15V SMPS Switching Power Supply, 3A/5A/8A

    ● Standard 15V DC switching power supply offers safe and stable power support, optional 50-120W. ● Stable output, low ripple, and strong anti‑interference for consistent performance. ● Mesh cooling design ensures heat dissipation, quiet operation and long service life. ● Premium structure and robust components ensure exceptional stability and long‑term durability.
    $54.15

    24V 2A 50W SMPS Switching Power Supply

    ● Provides reliable 24V/2.1A/50W output to ensure stable and secure power supply. ● Built-in short circuit and overload protection to ensure stable and safe operation. ● Rigorous burn-in test guarantees high stability and consistent performance. ● Efficient free air convection design for silent running and long service life.
    $54.15
    Overview

    5V switching mode power supply delivers 100W output with a 20A current rating, supporting universal input AC voltage via a manual selector switch to provide stable 5V DC power. Compact, cost-effective, and highly reliable, it is ideal for LED lighting, security cameras, communications gear, industrial control systems, and household electrical appliances. Affordable and built for long-term use, this power supply is ready for your various projects—order now and enjoy great value!

    5V 20A Switching Mode Power Supply Features

    Feature

    • Wide Compatibility: Universal AC input with selectable range via switch for flexible global usage.
    • User-friendly Design: User-friendly design with simple operation and convenient installation for easy daily use.
    • Full Protection: Built-in short circuit and overload protection ensures safe and stable operation.
    • Sturdy Structure: Durable housing and robust internal materials ensure excellent strength and long service life.


    Details

    1. Input 220V: Compatible with standard 220V AC household and industrial power systems.
    2. Ground Wire: Ensures safe electrical grounding to protect the unit and connected devices.
    3. Output Negative Terminal: Dedicated connection point for negative DC power output.
    4. Output Positive Terminal: Dedicated connection point for positive DC power output.
    5. Voltage Regulation: Allows precise adjustment of output voltage for stable device operation.
    6. Indicator Light: Provides instant visual confirmation of power-on status.
    5V 20A Switching Mode Power Supply Details

    Dimension (Unit: mm)

    5V 20A Switching Mode Power Supply Dimension

    100W SMPS Terminal Pin Number Assignment

    Specs
    Model PH-S-100-5
    Output DC Voltage 5V
    Rated Current 20A
    Current Range 0 ~ 20A
    Rated Power 100W
    Ripple & Noise (Max.)(Note 2) 100mVp-p
    Voltage Adjust Range 4.75 ~ 5.5V
    Voltage Tolerance (Note 3) ±2.0%
    Line Regulation ±0.5%
    Load Regulation ±0.5%
    Setup, Rise, Holdup Time 200ms, 80ms, 20ms at full load
    Input Voltage Range 85 ~ 132VAC/180V~264VAC (selected by a switch) or 255 ~ 370VDC
    Frequency Range 47~63Hz
    Efficiency (Typ.) 78%
    AC Current (Typ.) 2.4A/115V AC 1.2A/230V AC
    Inrush Current (Typ.) Cold start: 30A/115V AC 60A/230V AC
    Leakage Current <1mA/240V AC
    Protection Overload 105~150% rated output power
    Protection type: Shut down output voltage, re-power on to recover.
    Environment Working Temperature -10 ~ +60℃
    Working Humidity 20~90% RH non-condensing
    Storage Temperature -20~+85℃
    Storage Humidity 10~95% RH non-condensing
    Temperature Coefficient ±0.03%/℃ (0~50℃)
    Vibration 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes
    Safety & EMC (Note 4) Safety Standards UL1012 Approved
    Withstand Voltage I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
    Isolation Resistance I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC/25℃/70% RH
    EMC Emission Compliance to FCC Part 15 J conduction Class B
    Others MTBF ≥322.4K hrs MIN. MIL-HDBK-217F (25℃)
    Dimension 199*98*38mm (L*W*H)
    Weight 0.63kg
    Note 1. All parameters NOT specially mentioned are measured at 230V AC input, rated load and 25°C of ambient temperature.
    2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
    3. Tolerance includes set up tolerance, line regulation and load regulation.
    4. The switching power supply is considered a component which will be installed into final equipment. Please make sure that the final equipment still meets EMC directives.
    Application
    Household Appliances

    Household Appliances

    Factory Equipment

    Factory Equipment

    Monitoring Equipment

    Monitoring Equipment

    Power Tools

    Power Tools

    FAQ

    Q1: What is switching power supply's working principles?

    A switching power supply works by rapidly turning electronic switches on and off to convert input AC or DC voltage into high‑frequency pulses, which are then transformed, rectified, and filtered to produce a stable DC output; a feedback circuit continuously adjusts the switching duty cycle to maintain constant output voltage, making it highly efficient, compact, and widely used in electronic devices.

    Q2: What are common applications of switching power supplies?

    Switching power supplies are widely used in computers, laptops, mobile phone chargers, TVs, monitors, industrial equipment, LED lighting, automotive electronics, communication devices, medical instruments, and home appliances because they are efficient, compact, and able to provide stable voltage for various electronic products.
