    Picture of 12V 10A Linear Adjustable DC Power Supply, 120W
    Picture of 12V 10A Linear Adjustable DC Power Supply, 120W
    Picture of 12V 10A Linear Adjustable DC Power Supply, 120W

    12V 10A Linear Adjustable DC Power Supply, 120W

    2 review(s) | Add your review
    SKU: PH-DCPS-1210
    $291.49
    ● Supports continuous adjustment of 0–12V DC voltage, with 120W rated power to meet requirements across multiple scenarios. ● Adopts a linear series regulation design for high stability precision and low ripple voltage. ● Features over-voltage and over-current full protection with alarm functions, and alarm thresholds are user-configurable. ● Ideal for laboratory testing, electronic R&D, industrial equipment power supply, and educational electronics training.
    *
    🚚 Free shipping
    ⏱️ Delivery: 6-12 days
    🔙 30-day Returns
    Related products

    30V 3A Linear Adjustable DC Power Supply, 90W

    ● 0–30V voltage and 0–3A current are continuously adjustable, with a rated power of 90W. ● Humanized compact design, digital display with fine-tuning and coarse-tuning knobs. ● Built-in multiple protections, ensuring efficient operation and safety. ● Suitable for working environments of 0–40℃/85% RH, with strong stability.
    $181.79

    30V 5A Linear Adjustable DC Power Supply, 150W

    ● 0–30V voltage and 0–5A current are continuously adjustable, meeting the precise power supply requirements of various scenarios. ● Linear voltage regulation design, with ripple noise as low as 0.5mV, excellent load and line regulation performance. ● Excellent load/line regulation rate, stable temperature coefficient, and reliable long-term operation accuracy. ● A variety of voltage inputs are available, suitable for power grid environments in different regions around the world.
    $187.99

    30V 10A Linear Adjustable DC Power Supply, 300W

    ● Adopts a low-ripple linear topology, providing pure and stable power supply for precision electronic testing. ● Equipped with multiple safety protections such as overcurrent and overvoltage, which is efficient and reliable. ● The efficiency is greater than 65%, the recovery time is ≤100μs, and it can operate stably for a long time. ● A variety of input voltages are available, adapting to the power grid environments in different regions of the world.
    $550.49

    30V 20A Linear Adjustable DC Power Supply, 600W

    ● 20 amp 30 volt wide range adjustable, stable output with low ripple. ● Linear regulation, precise and reliable, meeting the needs of precision electronic testing and experiments. ● Built-in multiple protections against overcurrent and short circuit, effectively ensuring the safety of equipment and loads. ● Suitable for multiple scenarios such as scientific research experiments, teaching and training, production line testing, and equipment maintenance.
    $651.59

    30V 30A Linear Adjustable DC Power Supply, 900W

    ● 900W high power, 30V voltage and 30A current continuously adjustable, easily meeting the power supply needs of various devices. ● Ripple noise of 0.5mV, excellent load and linear regulation accuracy, providing a pure and reliable power supply environment. ● High conversion efficiency, reducing energy consumption and heat generation, making long-term full-load operation more stable and durable. ● User-friendly design with a portable handle for easy movement of the device in various scenarios.
    $889.69

    30V 60A Linear Adjustable DC Power Supply, 1800W

    ● 30V/60A continuously adjustable—delivers flexible power to suit a wide range of devices. ● Thoughtfully integrated carry handle allows quick and easy relocation across different workspaces. ● 0.5mV noise with exceptional load and line regulation, ensuring clean, stable power for sensitive applications. ● Minimizes energy loss and heat buildup, enabling long‑term full‑load operation with enhanced reliability.
    $1,796.99
    Overview

    Elevate your projects with our high-efficiency linear adjustable DC power supply—now available online at a competitive price point. This versatile unit delivers a robust 120W DC output in a switching-mode design, offering seamless adjustability from 0 to 10A and 0 to 12V. Engineered for precision, it maintains industry-leading constant voltage (CV) and constant current (CC) regulation, ensuring your critical applications receive a stable, reliable power source. Whether you’re powering R&D prototypes, industrial equipment, or electronic testing setups, this regulated linear DC power supply provides the consistent performance you need to drive innovation and operational excellence.

    Linear Adjustable DC Power Supply Features

    Feature

    • Energy-saving Performance: Conversion efficiency > 65%, ensuring stable output while reducing energy consumption and heat generation.
    • Dual-output Design: Adopting a dual-output structure, it can power two groups of devices simultaneously, improving the efficiency of experiments and production.
    • Wide Voltage Input Compatibility: Supports 110V/220V AC input, and can work stably in different power grid environments around the world.


    Details

    1. Status Indicator Lights: Clear constant voltage (CV) and constant current (CC) indicator lights allow intuitive judgment of the current operating mode.
    2. Digital Display: The high-brightness 3-digit digital screen displays the output voltage in real time, with a resolution of up to 100mV, meeting the requirements for precision experiments and testing.
    3. Dual Knobs: Equipped with coarse and fine adjustment knobs, it allows for quick large-range adjustment of output parameters and precise fine-tuning to the target value, balancing operational efficiency and adjustment accuracy.
    12V 10A Linear Adjustable DC Power Supply Detail

    12V 10A Linear DC Power Supply Dimension (Unit: mm)

    12V 10A Linear Adjustable DC Power Supply Dimension

    12V 10A Linear DC Power Supply Structure

    12V 10A Linear DC Power Supply Structure

    Specs
    Model PH-JK1210D
    Input Voltage 110V or 220V AC (+/- 10%)
    Output Voltage Range DC 0-12V
    Output Current Range 0-10A
    Output Power 120W
    Frequency 50Hz/60Hz
    Output Type Dual
    Display 3 digit
    Display Accuracy ≤ ±0.1%＋2d
    Voltage Display Resolution 100mV
    Current Display Resolution 100mA
    Efficiency >65%
    Voltage Regulation
    Load Regulation (CV) 1×10-5+2mV
    Line Regulation (CV) 1×10-5+5mV
    Ripple & Noise (P-P) 0.5mV
    Temperature Coefficient 300PPｍ/℃
    Current Regulation
    Load Regulation (CC) 5×10-5+10mV
    Line Regulation (CC) 3×10-5+10mA
    Temperature Coefficient 300PPｍ/℃
    Others
    Protection Over Load and Over Voltage Protection
    Recovery Time ≤100µs
    Operating Ambient -10℃ to + 45℃/ 85%RH
    Storage Ambient -10℃ to + 80℃/ 80%RH
    Warranty 12 Months
    Size 290 (L) x 130 (W) x 165 (H) mm
    Weight 5.5kg
    Application
    Electrochemical Experiment

    Electrochemical Experiment

    Automotive Motor

    Automotive Motor

    Electronic Component Testing

    Electronic Component Testing

    Display Screen and Electronic Device

    Display Screen and Electronic Device

    FAQ

    Q1: How do I calibrate linear DC power supply?

    To calibrate this linear adjustable DC power supply, first ensure it is off and connect a calibrated voltmeter to the output terminals. Set a target voltage, turn on the unit, and adjust the output knob until the voltmeter matches your desired value. Repeat this process across multiple voltage points to check for discrepancies. You can also calibrate the current limiting function with a calibrated ammeter and load resistor, then document all results and schedule periodic recalibration to maintain performance.

    Q2: What should I do if the linear DC power supply fails to output the set voltage?

    First, check if the unit is in constant current (CC) mode, as this will limit voltage output when the load draws more current than the set limit. Verify your load requirements and adjust the current limit accordingly, then confirm all connections are secure and free from short circuits. If issues persist, review the calibration records or perform a fresh calibration to ensure accuracy.

    2 review(s)
    5.0 2
    Write your own review Close
    *
    *
    Ethan | 8/12/2026 9:46 AM
    Solid DC Supply – Does the Job
    Clean, stable power, and the over-voltage protection is a nice touch. Price is fair for what you get – no complaints.
    Joren | 8/12/2026 1:04 AM
    Solid, Reliable Bench Power Supply for R&D
    Grabbed this 12V 10A DC power supply for my electronics bench, and it’s been rock solid. Clean output, very low ripple, and the coarse/fine control knobs make dialing in precise voltages effortless. The build feels sturdy and handles continuous loads like a champ without getting overly warm. Great value for any lab setup or DIY project!
