200W Constant Current LED Driver

SKU: PH-CCLD-200

$92.31

● 200W dimmable constant current LED driver with an efficiency of up to 92%. ● UL/CE/CCC/FCC certified & IP65/IP67 waterproof. 3 dimming modes are available. ● Supports adjustable output current, allowing for flexible matching with various LED lighting fixtures. ● Suitable for plant lights, street lights, stadium lights, fish-attracting lights, and therapeutic lights.

Dimming Method *

Qty:

🚚 Free shipping

⏱️ Delivery: 6-12 days

🔙 30-day Returns

Overview
Specs
Application
FAQ
Reviews

Overview

200W constant current LED driver for sale online. It is an LED power supply available with 3 dimmable methods, output voltage 28~56V, output current 3.0-5.6A, input voltage 100~277V AC, flicker-free output, 92% high efficiency, specially designed for plant cultivation.

Feature

3 in 1 Dimming (0–10V / PWM / Resistor): 200W LED driver power supply is compatible with multiple mainstream dimming methods, offering strong adaptability and stable and reliable dimming.
3 in 1 Dimming + 12V / 300mA Auxiliary Power Supply: Built-in 12V auxiliary power supply can power external control or dimming devices, simplifying system configuration.
Knob Dimming + (RJ11 Ethernet Port): Supports local knob dimming and can be connected to an external control system via the RJ11 interface.

Details

200W constant current LED light driver provides a stable current, ensuring uniform brightness of the LED chips and extending their lifespan.
It features multiple protections against overload, short circuit, overvoltage, overtemperature, and overcurrent, effectively ensuring the safe and stable operation of both the power supply and the LEDs.
Efficiency 92.0%, flicker-free output, effectively reducing energy consumption and providing a stable and comfortable lighting experience.
Dimmable LED power supply offers UL/CE/CCC/FCC certifications and an IP65/67 waterproof rating, suitable for long-term outdoor and humid environments.

200W Constant Current LED Driver Size (Unit: mm)

100W constant current LED driver size

L1	L2	L3	W1	W2	H
236	220	213	67	34	40

Specs

Output Voltage	28-56V
Output Current	3.0-5.6A
Output Power	200W
Effciency	92.0%
Power Factor	0.95
Input Voltage	100-277V AC
Lightning Protection	6kV/10kV
Function Options	Aux Power 12V/0.3A
Dimming Method	(Default) Knob Dimming + (RJ11 Ethernet Port)
	3-in-1 Dimming (0-10V/PWM/Resistor)
	3-in-1 Dimming + 12V/300mA Auxiliary Source
Output Frequency	50/60Hz
Certificated	UL/CE/CCC/FCC
Application	LED Lighting (Especially for Plant Grow Lights)
Waterproof Grade	IP65/IP67
Protection	Over-Heat, Over-Load, Short-Circuit & Open-Circuit
Test	100% Full Load Burn-in Test Over 4 Hours
Work Temperature	-40℃~+50℃
Storage Temperature	-40℃~+90℃
Relative Operation Humidity	10%RH~90%RH
Relative Operation Humidity	10%RH~90%RH
Shell Material	Aluminum

Application

Plant Lighting

Horticulture Lighting

LED Stadium Lighting

Fishing Lamp

FAQ

Q1: Is a 200W driver suitable for centralized lighting?

Yes, 200W constant current LED power supplies are commonly used in centralized or high-brightness lighting systems, such as plant lights, street lights, stadium lights, fish-attracting lights, and therapeutic lights. The higher power output reduces the number of drivers required, thus lowering wiring complexity and maintenance costs while maintaining good energy efficiency.

Q2: Can a 200W driver handle grid voltage fluctuations?

This 200W constant current LED driver supports a wide input voltage range of 28-56V, maintaining a stable output current even under significant power grid voltage fluctuations. This feature is particularly important in industrial sites or areas with unstable power conditions, helping to avoid LED brightness variations and frequent failures.
